Product description
Steel gutters of the highest quality and very high durability.
Four protective layers protect the gutters against the negative effects of weather conditions, and the thickness of the steel core is 0.6 mm.
It is galvanized, passivated on both sides and covered with a protective and aesthetic organic coating.
The Galeco STEEL gutter system is made of the best quality coated steel. Steel gutters and downspouts are protected by four protective layers: zinc, a passivation layer, an undercoat and an organic coating. It is the only COMPLETE GUTTER AND DRAIN PIPE PROTECTION system on the market: foiling and internal seam of the pipe, guarantees high aesthetics and no scratches.
Gutter material
Gutters from the Galeco STAL system are made of the highest quality coated steel. The high durability of the sheets is ensured by the additional use of four protective layers that protect metal gutters from the negative effects of weather conditions. The thickness of the steel core is 0.6 mm. It is galvanized, passivated on both sides and covered with a protective and aesthetic organic coating.
Color
| Gutter type / pipe size | |||||
|---|---|---|---|---|---|
| RAL color | 120/90 | 135/90 | 135/100 | 150/100 | 150/120 |
| D Brick red (~ RAL 8004) | |||||
| V Dark brown (~ RAL 8019) | |||||
| E Chocolate brown (~ RAL 8017) | |||||
| H Copper (~ RAL 8007) | |||||
| W White (~ RAL 9003) | |||||
| B Black (~ RAL 9005) | |||||
| P Dark red (~ RAL 3009) | |||||
| A Graphite (~ RAL 7015) | |||||
| I Silver (~ RAL 9006) | |||||
| Y Graphite SEMI-MATTE (~ RAL 7016) | |||||
| U Black SEMI-MATTE (~ RAL 9005) | |||||
| K Chocolate brown SEMI-MATTE (~ RAL 8017) | |||||
Performance table
The table below describes the performance of the Galeco STAL system depending on the location of the downpipe.
| Gutter type / pipe size | |||||
|---|---|---|---|---|---|
| Drain pipe settings | 120/90 | 135/90 | 135/100 | 150/100 | 150/120 |
 |
60 m 2 |
110 m 2 |
110 m 2 |
150 m 2 |
150 m 2 |
 |
120 m 2 |
220 m 2 |
220 m 2 |
300 m 2 |
300 m 2 |
norms
Polish Standard PN-EN 612 regarding gutters, pipes and fittings - May 2006, "Roof gutters made of metal sheets with a round stiffened edge on the front side and downspouts connected with the plant".
Polish Standard PN-EN 1462 - April 2006, "Gutter brackets. Requirements and tests ”- regarding hooks.
Our own declarations have been confirmed by tests at the Building Research Institute: test reports no:
LOW / 019.1 / 2007, LOW / 019.2 / 2007, LOW / 108.1 / 2008, LOW-537.1 / 2009.
Corrosivity classes
| Grade | corrosivity | Example of an environment |
|---|---|---|
| C1 | VERY LOW | Heated places with dry air and low levels of pollution, e.g. offices, schools and hotels. |
| C2 | SHORT | Places with low levels of air pollution. Unheated places with varying temperatures and humidity. Low condensation frequency and low level of air pollution, e.g. fitness centers, warehouse buildings. |
| C3 | MODERATE | Places where salt or air pollution is moderate. Urban areas, light industry zones and areas under some influence of the coastal environment. Places with moderate humidity and those where some of the air pollutants are present, such as brewhouses, dairies, laundries, etc. |
| C4 | TALL | Places with moderate salt levels or moderate levels of air pollution. Industrial and coastal areas. Places with high humidity and high levels of air pollution from production processes, e.g. chemical industry, indoor swimming pools, shipyards. |
